SINGLE GIRDER EOT CRANE

SALIENT FEATURES :

Design : "BAHUCHAR ELECTRICALS" are designed & manufactured in accordance with IS-807, IS-3177 & IS-4137, considering the factor of safety in respect to the appropriate class of duty.

Duty :

BE Cranes are designed for various classes of duties:

• Class I : Light duty cranes for maintenance and workshop operations.
• Class II : Medium duty cranes for general engineering applications and machine shops.
• Class III : Heavy duty cranes for heavy machine & fabrication shops, paper mills, etc.
• Class IV : Extra heavy-duty cranes for continuous operations in steel mills and other heavy engineering purposes.

Crane Bridge :

Crane bridge girders are of plate box type/standard rolled steel joist/compound beams/castellated lattice construction. The material of construction conforms to IS: 2062-1992, ensuring 100% reliability of joints.

Motors :

The motors used are specially crane duty (S4) suitable for frequent starting, reversing & braking, constructed in dust proof and fan cooling (TEFC).

Brakes :

Electromagnetic single - dual AC Disc Type/Electromagnetic Shoe type/EHT Brakes are provided in all motions. The motors are equipped with "FAIL TO SAFE" brakes, automatically releasing when the motor circuit is off.

Gear Box :

The entire gear boxes are made of accurate hob cut helical/spur gear and pinions running on antifriction bearings for smooth operation & long life.
